Bayonet 350
Product descripton: Bayonet 350 by Greensea IQ
The Bayonet 350 is the largest Autonomous Underwater Ground Vehicle (AUGV) in the Greensea IQ Bayonet series, designed to operate in the harshest maritime environments from the seafloor to the beachhead. Engineered for the heaviest payloads and the most demanding environmental conditions, it delivers exceptional capability for defense, scientific, and commercial missions.
Its scalable architecture allows the chassis to be customized to specific payload requirements, making it suitable for applications requiring significant carrying capacity and robust operational performance. The Bayonet 350 is designed to support complex scientific research, extensive military operations, and demanding commercial tasks where reliability and payload flexibility are critical.
Technical specifications
| Specification | Value |
|---|---|
| Vehicle Type | Autonomous Underwater Ground Vehicle (AUGV) |
| Dimensions | 72 × 59 × 14 in (182.9 × 152.4 × 45.7 cm) |
| Open Deck Space | 55 × 28 in (139.7 × 71.1 cm) |
| Weight (with Batteries) | 600 lb (272 kg) |
| Battery Capacity | 2 kWh (standard), +2 kWh (extended) |
| Platform | Greensea Core Platform |
| Processor | Greensea IQNS |
| Maximum Depth | 100 m |
| Range (Dry / Wet) | 6 nmi / 8 nmi |
| Duration | Approx. 2 hours |
| Maximum Speed | Up to 1 knot |
| Deck Capacity | 300 lb (136 kg) continuous, 620 lb (281 kg) peak |
| Navigation & Positioning | Greensea IQ OPENINS |
| Software Platform | OPENSEA |
| Command & Control Software | Greensea IQ Workspace user interface |
| Use Case | Large & capable |
Key Features
- Amphibious / surf zone capable
- 100 m depth rated
- Modular components for simplified logistics
- Large deck space for payload and mission flexibility
- Advanced navigation with Fiber Optic Gyroscope (FOG)
- Field-swappable battery packs (one per pontoon)
Interface & Electrical
- 24 VDC, 250 W power
- 6 × Gigabit Ethernet ports
Sensor Packages
Standard
- Depth sensor
- Camera
- Forward-looking sonar
- GPS (Advanced Navigation)
- IP Radio – 70 Mbps (approx.), line-of-sight range: 100 m
Optional
- Acoustic communications (ACOMMS)
- RTK GPS
- Doppler Velocity Log (DVL)
