FLEX FPV
Product descripton: FLEX FPV by Draganfly Drones
The Draganfly Flex FPV is a modular first-person view (FPV) unmanned aerial vehicle (UAV) designed for tactical reconnaissance, rapid situational awareness, and time-critical defense operations. Built to meet government and military requirements, the platform combines high-speed flight, configurable payload capacity, and mission-specific adaptability within an NDAA-compliant architecture.
Designed for fast-response operations, the Flex FPV delivers real-time FPV video, high maneuverability, and rapid deployment for reconnaissance, inspection, target observation, and tactical missions. Operators can further customize the platform with optional payload modules, mission recording capabilities, and different power configurations to match evolving operational requirements.
Its mission-focused design provides a scalable UAV solution that balances agility, endurance, and lifting capability, making it suitable for defense, public safety, and other applications requiring rapid aerial intelligence and flexible mission execution.
Core Capabilities
- Tactical FPV reconnaissance and situational awareness
- Modular multi-configuration airframe (5″, 7″, 10″, and 13″)
- Configurable payload capacity and flight performance
- High-speed maneuverable flight
- Real-time FPV video transmission
- NDAA-compliant platform for government and defense use
- Mission-specific payload integration
- Quick-exchange modular arm system
- Configurable balance of speed, endurance, and payload
- Rapid deployment for dynamic operational environments
Technical specifications
Draganfly Flex FPV Specifications
Flex FPV Key Features
| Feature |
|---|
| Quick-swap arms offer 4 size options |
| Monitor and upload missions via MAVLink |
| First-person piloting for advanced manoeuvres |
| NDAA compliant |
Common & Core Specifications
| Specification | Value |
|---|---|
| Flex FPV Core Mass | 500 g |
| Number of Propellers | 4 |
| Propeller Configuration | X |
| GPS/Compass | ARK SAM GPS Mini |
| Camera | KT & KPC-C20NUB |
| Payload Attachment | Picatinny Rail |
| Flight Controller | Orqa F405 |
| ESC | MAD 70A 4-in-1 |
| RC Link | 2.4 GHz IRC Ghost |
| Video Link | 5.8 GHz Analog |
| Telemetry Link | 915 MHz RFD900ux |
| Max Radio Range | 10 km |
Variant Specifications
| Specification | Flex FPV 5 | Flex FPV 7 | Flex FPV 10 | Flex FPV 13 |
|---|---|---|---|---|
| Assembled Mass (with battery) | 1,550 g | 1,800 g | 3,100 g | 5,800 g |
| Max Payload | 450 g | 1 kg | 2 kg | 3 kg |
| Assembled Dimensions (L × W × H) | 250 × 250 × 60 mm | 415 × 415 × 60 mm | 570 × 570 × 60 mm | 665 × 665 × 60 mm |
| Battery Configuration | 6S | 6S | 12S | 12S |
| Battery Capacity | 7,000 mAh | 7,000 mAh | 7,000 mAh | 14,000 mAh |
| Hover Endurance (No Payload) | 15 min | 20 min | 30 min | 40 min |
| Hover Endurance (Max Payload) | 3 min | 8 min | 10 min | 15 min |
| Range (No Payload) | 10 km | 20 km | 30 km | 40 km |
| Range (Max Payload) | 5 km | 10 km | 15 km | 20 km |
| Suggested Max Speed | 120 km/h | 150 km/h | 150 km/h | 150 km/h |
Production Schedule
| Timeline | Production Rate |
|---|---|
| T + 3 Months | 100/month |
| T + 4 Months | 350/month |
| T + 6 Months | 1,000/month |
| T + 9 Months | 2,500+/month |
