HLM Industrial Hexacopter
Product descripton: HLM Industrial Hexacopter by Aero Systems West
The HLM Industrial Hexacopter is a robust, industrial-grade UAV designed to deliver maximum payload capacity with unmatched reliability. Featuring six powerful motors and multiple redundant systems, this hexacopter ensures mission continuity even under demanding conditions. With up to 60 minutes of flight time and a maximum payload of 30 kg (66 lbs), it provides the endurance and flexibility required for industrial applications such as construction, heavy-lift transport, and complex inspection operations. Its modular design and adjustable frame height allow customization to suit diverse operational needs, while dual LiPo battery options extend flight duration and mission versatility.
Key Advantages
-
High Payload Capability: Supports up to 30 kg (66 lbs) with standard and optional modular mounting systems.
-
Redundant & Reliable: Multiple redundant systems provide enhanced operational uptime and safety.
-
Extended Flight Time: Up to 60 minutes of endurance for long industrial missions.
-
Industrial-Grade Construction: Six high-power motors and a durable airframe handle heavy-lift tasks with precision.
-
Modular & Customizable: Adjustable height and ground clearance to optimize performance for specific payloads.
-
Autonomous & Efficient: Capable of autonomous flight modes for streamlined mission execution.
-
Transport-Friendly: Easily stored and transported in a LightFlite hard shell case.
Applications
-
Heavy-lift industrial transport and logistics
-
Large-scale infrastructure inspection
-
Construction site monitoring
-
Environmental research and scientific missions
Technical specifications
| Specification | Value |
|---|---|
| Payload Capacity | 30 kg (66 lbs) |
| Motors | 6 × 1658 mm diameter |
| Max Flight Time | 60 minutes |
| Max Forward Flight Range | ~37 km (23 mi) |
| Service Ceiling | 3600 m MSL |
| Max Takeoff Weight (MTOW) | 55 kg (121 lbs) |
| Battery Configuration | Dual LiPo Packs (standard or extended range) |
| Payload Mounting | Standard slot patterns, optional rails |
| Transport & Storage | LightFlite hard shell case |
| Key Features | High endurance, heavy-lift tested, industrial grade, modular design, autonomous |
