L30
Product descripton: L30 by OceanAlpha
Engineered for patrol, security, search & rescue, and logistics operations, the L30 Unmanned Surface Vehicle (USV) delivers proven reliability through continuous refinement.
Designed for coastal authorities, maritime agencies, and offshore operators, it excels in maritime safety, offshore infrastructure protection, and law enforcement missions.
Technical specifications
Key Features
Powerful Performance & Endurance
The 7.5 m deep-V aluminum hull with an aggressive axe bow cuts through waves effortlessly, combining high-speed agility with exceptional stability.
With a 4.5-ton displacement and 220-nautical-mile range, the L30 maintains mission readiness in challenging offshore conditions.
Agile Propulsion System
Powered by twin diesel engines with configurable waterjet or shaft-drive propulsion, the L30 achieves 35-knot bursts and operates reliably in Sea State 3.
Its three intelligent control modes adapt seamlessly to mission requirements.
Advanced Situational Awareness
A sophisticated sensor suite includes:
- Radar
- LiDAR
- 360° imaging
- Starlight cameras
- Electro-optics
Integrated with AIS and electronic charts, it detects vessels, personnel, buoys, and underwater hazards in all conditions.
Modular Mission Flexibility
Equipped with interchangeable payloads, the L30 supports:
- Non-lethal acoustic deterrents
- Drone detection
- Rescue equipment
- Electronic fencing
This enables rapid adaptation to security, emergency response, and operational support missions.
Intelligent Autonomy
Built around a next-generation control system, the L30 navigates complex waterways with obstacle avoidance and real-time decision-making.
It automatically returns to base when encountering extreme conditions, ensuring mission continuity.
Technical Specifications
| Category | Specification | Value |
|---|---|---|
| Physical | Dimensions | 7.5 m (L) × 2.6 m (W) |
| Weight | 4.5 t | |
| Draught | 0.6 m | |
| Hull Material | Aluminum-Magnesium Alloy | |
| Performance | Maximum Speed | 36 kn |
| Endurance | 280 nm @ 25 kn | |
| Operation Sea State | Sea State III | |
| Payload | 300 kg | |
| Power & Propulsion | Propulsion | 2 × Steyr Diesel Engines + 2 × Alamarin Waterjets |
| Power for Electronics | Battery Pack + Diesel Generator | |
| Fuel Capacity | Diesel 700 L | |
| Navigation Aids & Safety | Situation Awareness | Navigation Radar, LiDAR, AIS, Camera, Echo Sounder |
| Collision Avoidance | Dynamic / Static Collision Avoidance | |
| Control & Communication | Control Mode | Remote Control / Autonomous / Manual |
| Communication | Private Network (10–20 km), Remote Controller (1 km), Public Network, Satellite Communication, On-board VHF Radio | |
| Software | OceanAlpha USV Navigation & Mission Software |
