REMUS 130
Portable Modular Unmanned Underwater Vehicle for Survey, MCM, ISR, and Multi-Mission Operations
Product descripton: REMUS 130 by Huntington Ingalls Industries (HII)
REMUS 130 is a third-generation portable unmanned underwater vehicle (UUV) developed by HII Mission Technologies as the latest evolution of the REMUS 100 series. Built on the proven technology platform of the REMUS 300, it combines modular design, open architecture, and enhanced underwater performance while reducing cost and risk. Powered by the Odyssey™ autonomy suite, REMUS 130 supports collaborative autonomy and fleet interoperability across a wide range of commercial, scientific, and defense missions.
Key Features
- Small-class, two-person portable design
- Modular and reconfigurable architecture
- Open architecture for rapid payload integration
- Odyssey™ cross-domain autonomy suite
- Fleet interoperability with the REMUS family
- Scalable modular payload space
- Flexible energy options with blind-mated end caps for rapid field battery exchange
- Long service life
- Cost-effective platform
Mission Applications
- Mine Countermeasures (MCM)
- Search and Recovery (SAR)
- Rapid Environmental Assessment (REA)
- Marine Archaeology
- Offshore Oil and Gas Exploration
- Renewable Energy Inspection
- Intelligence, Surveillance and Reconnaissance (ISR) (optional payload)
- Anti-Submarine Warfare (ASW) (optional payload)
Advantages
- Common technology platform for fleet interoperability
- Modular and reconfigurable for diverse mission profiles
- Open architecture supporting rapid payload integration
- Cost-effective design with long service life
- Customer-defined missions enabled by scalable modular payload space
Technical specifications
| Parameter | Specification |
|---|---|
| Size | Small-class |
| Portability | Two man-portable |
| Depth Rating | 100 meters |
| Endurance | Up to 10 hours |
| Range | Up to 55 km |
| Speed | Greater than 4.0 knots |
| Lithium-Ion Battery Options | 1.5 kWh |
| Hard Drive | Removable 1 TB hard drive |
| Sonar | Standard 900/1800 kHz dual frequency side-scan sonar; Resolution up to 5 cm; Swath up to 160 m |
| Optional Payloads | Synthetic Aperture Sonar, Camera, Laser Scanner, Magnetometer, Multi-Aperture Sonar, User Defined Payloads, Third Party Autonomy |
